Tile lippage credit card test
What is Tile Lippage?
Lippage refers to the difference in height between the edges of adjacent tiles. This variation in elevation can impact the visual appeal and even the safety of a tiled surface.
The American National Standards Institute (ANSI) standard A108.02, Section 4.3.7, defines lippage as 'differences in elevation between edges of adjacent tile modules.'
Factors Influencing Lippage Perception
Several factors can influence how noticeable lippage appears. These include the inherent thickness variations of the tile modules, their allowable warpage, and the spacing between them. The way light hits the surface, especially at an angle, can accentuate even minor variations. Highly reflective tile surfaces can also make otherwise acceptable variances more apparent.
Furthermore, the flatness of the substrate beneath the tiles plays a crucial role. If the substrate is uneven, the installed tile surface may not meet lippage standards, particularly when using the thinset installation method.
The 'Credit Card Test' and Acceptable Variations
While not a formal ANSI standard, the 'credit card test' is a common field method used to assess lippage. If a credit card can slide freely under the edge of one tile and over the edge of an adjacent tile, it generally indicates an unacceptable level of lippage. This test is a practical way to identify potential issues before they become significant problems.
It's important to remember that some degree of lippage is often unavoidable due to manufacturing tolerances and installation variables. The ANSI standards aim to define acceptable limits for these variations to ensure a satisfactory finished product. For accurate project planning and material estimation, consider using a free tile calculator.
Key takeaways
- Lippage is the height difference between adjacent tiles, defined by ANSI standards.
- Light, tile reflectivity, and substrate flatness significantly affect the perception of lippage.
- The 'credit card test' is a practical method to identify unacceptable lippage.
